RPF – Rotary Piston Filler
RPF – rotary piston fillers are automatic machines that are fast, flexible, and reliable. They accommodate a wide range of containers and products of most viscosities at high production speeds of 600+ per minute. The overhead driven pistons feature fine fill piston adjustment, achieving ±0.5% fill accuracy. Cylinders and pistons are easily removed for cleaning or changeover to other sizes.
RFL – Rotary Fill-To-Level
RFL – Rotary Fill-To-Level is a fully automatic machine that fills a variety of liquids with speeds up to 900 containers per minute with fill volumes ranging from .5 oz to 1 gallon and a fill accuracy of +/- 1/16 inch. All RFL fillers feature a top gear drive shielded to assure cleanliness and include centrally clustered manual lubrication systems for ease of maintenance.
The Versa-Fil is an accurate high-speed rotary time/pressure filler that is especially well suited to filling heavy viscosity food products like mayonnaise, peanut butter and relish as well as a variety of lighter products. It can be equipped with 4 to 24 spouts, with a maximum container diameter from 3.14″ to 8.50.” This machine can be designed to handle fill volumes as small as 5 cc up to imperial gallons, with a fill accuracy of +/- .5%.
IPF – Inline Piston Filler
IPF – Inline Piston Filler series is ideally suited for filling a diverse range of products and is equipped with 2, 4, or 6 heads. These fillers are ruggedly designed, yet precision built, for long trouble-free operation. The IPF – Inline Piston Filler will fill product volumes from 0.37 to 157 ounces with a single stroke (depending on cylinder and piston sizing) into metal, plastic, glass or rigid paper containers. Larger fills are attainable with multiple strokes into the same container. Product viscosity may range from 1-100,000 centipoises and above. With proper nozzle and cylinder sizing, this machine guarantees accuracies of +\- 1/2 of 1% of the fill volume.
IFL – Inline Fill-To-Level
IFL – Inline Fill-To-Level fills a diverse range of liquid products in a variety of container shapes and sizes, and it can be equipped with 2-12 nozzles. Models range from semi to fully automatic with speeds of 14-46 containers per minute and a fill accuracy of +/- 1/16 inch.
BMSV – Bench Model Piston Filler
BMSV – Bench Model Piston Filler. This Single Valve filling machine has been designed specifically to provide accurate economical filling of viscous products for lab work and small scale filling operations. The Bench Model is ideal for filling food sauces, paints, syrups, honey, caulks, etc. The unit features fully pneumatic operation and provides accuracy of up to +/- .05%, by volume dependent on products viscosity and flow characteristics.
